SELECTABLE WATTAGE OPTIONS
| SKU | SIZE | WATTAGE | POWER SELECTABLE | OUTPUT | CCT SELECTABLE | CRI | VOLTAGE | UL | DLC | DLC ID |
| GKOPLG314B32W27VDDKW | 1′ x 4′ | 32W | Selectable | 4,500 Lumens | 6500K, 5000K, 4000K, 3500K, & 3000K | 80 | 120-277V | Damp Locations | Premium | PENDING |
| GKOPLG322B32W27VDDKW | 2′ x 2′ | 32W | Selectable | 4,320 Lumens | 6500K, 5000K, 4000K, 3500K, & 3000K | 83 | 120-277V | Damp Locations | Premium | S-H70Z93 |
| GKOPLG324B43W27VDDKW | 2′ x 4′ | 43W | Selectable | 5,805 Lumens | 6500K, 5000K, 4000K, 3500K, & 3000K | 84 | 120-277V | Damp Locations | Premium | S-66G0YB |
| GKOPLG324B71W27VDDKW | 2′ x 4′ | 71W | Selectable | 10,000 Lumens | 6500K, 5000K, 4000K, 3500K, & 3000K | 80 | 120-277V | Damp Locations | Premium | PENDING |
SINGLE WATTAGE OPTIONS
| SKU | SIZE | WATTAGE | POWER SELECTABLE | OUTPUT | CCT SELECTABLE | CRI | VOLTAGE | UL | DLC | DLC ID |
| GKOPLG322B26W27VDDKW | 2′ x 2′ | 26W | Single Wattage | 3,640 Lumens | 6500K, 5000K, 4000K, 3500K, & 3000K | 83 | 120-277V | Damp Locations | Premium | S-5MFTY8 |
| GKOPLG324B30W27VDDKW | 2′ x 4′ | 30W | Single Wattage | 4,170 Lumens | 6500K, 5000K, 4000K, 3500K, & 3000K | 84 | 120-277V | Damp Locations | Premium | S-DV0JXF |
| GKOPLG324B36W27VDDKW | 2′ x 4′ | 36W | Single Wattage | 4,932 Lumens | 6500K, 5000K, 4000K, 3500K, & 3000K | 84 | 120-277V | Damp Locations | Premium | S-6G2V36 |
Visit the Design Lights Consortium website for more information on product DLC qualification.
DLC 6.0 PREMIUM
Series GKOPLG3 LED panels are a cost-effective, efficient replacement for fluorescent fixtures in commercial settings with recessed or suspended grid ceilings, such as office or retail spaces. Power & CCT Adjustment Controls are optional, featuring 4 power and 5 CCT settings that may be easily adjusted during installation using accessible switches. An ultra-slim 1.4″ profile reduces shipping costs and simplifies installation.
An optional Bluetooth NLC Listed PIR motion sensor with an easy to install locking Plug & Play design adds advanced lighting capabilities for more complex projects. .
Applications
OFFICE, RETAIL, AND INSTITUTIONAL SETTINGS WITH SUSPENDED GRID OR RECESSED CEILINGS
Customer-Focused Features
|
OPTIMAL MATERIALS Galvanized Steel Plate Housing with Frosted PS Diffuser
|
DIMMABLE CONTROLS 0-10V Dimmable Control Allows for Customized Lighting Outputs
|
|
OPERATING TEMPERATURES Rated for Temperatures from -4˚F to 122˚F (-20˚C to 50˚C)
|
MEETS ANSI/IEEE C62.41.2 1kV Surge Protection Standard
|
