| SKU | WATTAGE | SIZE | OUTPUT | CCT | CRI | VOLTAGE | REPLACES | UL | DLC | DLC ID |
| GKOMLHG490W27V50KCD | 90W | 1' x 2' | 12,600 Lumens | 5000K / 4000K | 80 | 120-277V / 347-480V | (3) F54T5, (4) F32T8,or 250W HID | Damp Locations | Premium | PL0EEJK2YKY1 |
| GKOMLHG4130W27V50KCD | 130W | 1' x 2' | 18,500 Lumens | 5000K / 4000K | 80 | 120-277V / 347-480V | (4) F54T5, (6) F32T8, or 400W HID | Damp Locations | Premium | PLZQQOK2MINV |
| GKOMLHG4B130W27V50KCD | 130W | 2' x 2' | 18,500 Lumens | 5000K / 4000K | 80 | 120-277V / 347-480V | (4) F54T5, (6) F32T8, or 400W HID | Damp Locations | --- | --- |
| GKOMLHG4180W27V50KCD | 180W | 2' x 2' | 25,200 Lumens | 5000K / 4000K | 80 | 120-277V / 347-480V | (6) F54T5, (8) F32T8, or 500W HID | Damp Locations | Premium | PLWV6BLIY53K |
| GKOMLHG4210W27V50KCD | 210W | 2' x 2' | 29,000 Lumens | 5000K / 4000K | 80 | 120-277V / 347-480V | (8) F54T5 or (10) F32T8 | Damp Locations | Premium | PLFXG841GUVS |
| GKOMLHG4L130W27V50KCD | 130W | 1' x 4' | 18,500 Lumens | 5000K / 4000K | 80 | 120-277V / 347-480V | (4) F54T5, (6) F32T8, or 400W HID | Damp Locations | Premium | PLDEB7DN2SFZ |
| GKOMLHG4L180W27V50KCD | 180W | 1' x 4' | 24,000 Lumens | 5000K / 4000K | 80 | 120-277V / 347-480V | (6) F54T5, (8) F32T8, or 500W HID | Damp Locations | Premium | PLIHTXA99V3K |
| GKOMLHG4L210W27V50KCD | 210W | 1' x 4' | 29,000 Lumens | 5000K / 4000K | 80 | 120-277V / 347-480V | (8) F54T5 or (10) F32T8 | Damp Locations | --- | --- |
| GKOMLHG4270W27V50KCD | 270W | 2' x 4' | 37,000 Lumens | 5000K / 4000K | 80 | 120-277V / 347-480V | (12) F54T5 or (14) F32T8 | Damp Locations | Premium | PLV012FGRL6O |
| GKOMLHG4300W27V50KCD | 300W | 2' x 4' | 41,500 Lumens | 5000K / 4000K | 80 | 120-277V / 347-480V | (16) F54T5, (18) F32T8, or 1,000W HID | Damp Locations | Premium | PLZXD752ZA8J |
| GKOMLHG4370W27V50KCD | 370W | 2' x 4' | 50,500 Lumens | 5000K / 4000K | 80 | 120-277V / 347-480V | (20) F54T5 or (24) F32T8 | Damp Locations | Premium | PL34ONF7JZ9S |
Visit the Design Lights Consortium website for more information on product DLC qualification.
High Efficacy With Multiple Mounting Options
The Series GKOMLHG4 LED Linear High Bay is an ideal one-to-one replacement for a conventional HID, T5, or T8 linear fixture, for mounting heights ranging from 15’ to 60’. Available in sizes of 1×2, 2×2, 1×4, and 2×4, these commercial ceiling lights excel at providing reliable, energy-efficient LED lighting in industrial and commercial applications.
Optional Multi-Level Motion Sensors are available for greater energy savings, and optional Battery Backups can provide up to 90 minutes of emergency operation during a power outage.
Applications
WAREHOUSES, WORKSHOPS, CONVENTION CENTERS, GYMNASIUMS, FACTORIES
Customer-Focused Features
|
OPTIMAL MATERIALS Cold-Rolled Steel Housing and Clear Polycarbonate Lens
|
DIMMABLE CONTROLS 1-10V Dimmable Control Allows for Customized Lighting Outputs
|
|
OPERATING TEMPERATURES Rated for Temperatures from -40˚F to 131˚F (-40˚C to 55˚C)
|
MEETS ANSI/IEEE C62.41.2 Integrated 6KV Surge Protection
|
